AL-F OEM
An OEM fiber laser system designed for integration into automated welding cells, robots and special-purpose machines, with scalable power options and integrated safety.
- 300–900 W Laser power
- PL d TÜV-verified safety
- 4 Power classes
- Upgradeable Power options
Product description
Built for Machine Integration
AL-F OEM is a modular fiber laser platform designed to become part of an automated welding system. It can be integrated into new or existing machine concepts, robotic cells and multi-axis positioning systems, giving OEMs flexibility in how the laser source, motion system and welding head are configured.
Scale Power as Requirements Grow
The system is available in 300 W, 450 W, 600 W and 900 W versions. The 300 W model can be upgraded to 600 W, while the 450 W version can be upgraded to 900 W, allowing the system to accommodate increasing production requirements without replacing the complete laser platform.
Process Monitoring at the Welding Head
The AL-F OEM can be paired with the AL-AKO K camera laser head for visual monitoring of the welding process or the AL-AKO M microscope laser head for manual precision welding. Both options are designed to support controlled shielding gas delivery and clear observation of the weld pool.
Control Motion and Laser Together
When integrated with robots, positioning systems or custom multi-axis machinery, the laser control can coordinate motors and axes with laser parameters. This allows the welding process and component movement to work as part of a single automated sequence.
Integrated Safety Concept
The AL-F OEM incorporates a safety concept verified by TÜV to Performance Level d, providing a defined safety foundation for integration into industrial laser systems.
Features
OEM-Ready Fiber Laser Platform
Designed specifically for integration into automated production lines, robotic cells and special-purpose machines.
Four Power Classes
Choose from 300 W, 450 W, 600 W and 900 W fiber laser configurations according to the requirements of the application.
Upgradeable Power
The 300 W and 450 W models can be upgraded to 600 W and 900 W respectively, providing a route to higher laser power as production requirements change.
Robot & Multi-Axis Integration
The system can be combined with robots, positioning systems and customized motion concepts for automated welding applications.
Camera-Based Process Monitoring
The compatible AL-AKO K camera laser head allows operators to monitor the welding process during operation.
Microscope-Assisted Welding
The AL-AKO M microscope laser head supports manual welding where detailed observation of the welding area is required.
Integrated Safety Concept
The system features an integrated safety concept verified by TÜV to Performance Level d.
Flexible Fiber Delivery
Fiber delivery allows the laser source to be connected to fixed optics or mobile processing heads according to the machine configuration.
AL-F OEM models
| Specification | AL-F OEM 300 | AL-F OEM 450 | AL-F OEM 600 | AL-F OEM 900 |
|---|---|---|---|---|
| Laser Type | Fiber laser | Fiber laser | Fiber laser | Fiber laser |
| Laser Power | 300 W | 450 W | 600 W | 900 W |
| Integration | OEM integration into automated systems or special machines | OEM integration into automated systems or special machines | OEM integration into automated systems or special machines | OEM integration into automated systems or special machines |
| Safety Concept | Integrated, TÜV-verified to Performance Level d | Integrated, TÜV-verified to Performance Level d | Integrated, TÜV-verified to Performance Level d | Integrated, TÜV-verified to Performance Level d |
| Upgrade Option | Upgradeable to 600 W | Upgradeable to 900 W | — | — |
| Monitoring Options | AL-AKO K camera / AL-AKO M microscope | AL-AKO K camera / AL-AKO M microscope | AL-AKO K camera / AL-AKO M microscope | AL-AKO K camera / AL-AKO M microscope |
Maintenance & care
Follow the recommended maintenance procedures for the selected laser source and integrated welding head. Keep optical components and fiber connections clean and protected and inspect the integrated system components as part of the machine's scheduled service routine.
May we help?
- What makes AL-F OEM different from a standard fibre laser welding machine?
- AL-F OEM is designed as an integration platform rather than a standalone welding workstation. It can be incorporated into robots, multi-axis systems and special-purpose machines as the laser source.
- Can the laser power be upgraded later?
- Yes. The 300 W version can be upgraded to 600 W, while the 450 W version can be upgraded to 900 W, allowing the laser system to scale with changing production requirements.
- How can the welding process be monitored?
- The AL-F OEM is compatible with the AL-AKO K camera laser head for process monitoring and the AL-AKO M microscope laser head for manual welding with detailed weld-area observation.
