HAN'S GRC4 1800
Coil Laser Cutting Machine — 10000mm x 1800mm working area (l x w), 120m/min max. positioning speed (x/y), ±0.5mm/m accuracy (x/y).
- 10000mm x 1800mm Working Area (L x W)
- 120m/min Max. Positioning Speed (X/Y)
- ±0.5mm/m Accuracy (X/Y)
- +0.03m Repeatability (X/Y)
Product description
The GRC4-1800 is suited for high-volume sheet-metal processing from coil, automotive and auto-component parts, electrical enclosures, HVAC components and general fabrication. Inspect the coil loading and material path before startup. Load the coil and set the feed parameters, then select the cutting program and material settings. Check the focus, nozzle, assist gas and cooling system before the initial cut. Verify the part dimensions and continue the feed-and-cut cycle while monitoring material tracking. Collect finished parts, manage scrap and clean the cutting and feeding area after production.
- Continuous coil feeding reduces repeated manual sheet loading.
- CNC programming supports repeatable part geometry.
- Integrated material handling supports continuous production flow.
- Supports positioning performance of ±0.5 mm/m accuracy and +0.03 mm
- Suitable for repetitive sheet-metal production.
Features
Coil-Fed Laser Cutting
Configured for continuous laser cutting from coil-fed sheet material.
Large Working Area
Provides a working area of 10000 × 1800 mm.
High Positioning Speed
Supports maximum X/Y positioning speed of 120 m/min.
CNC-Controlled Processing
Supports programmed cutting of sheet material from coil.
Continuous Material Feeding
Integrates material feeding and laser cutting for continuous production.
Specifications
| Specification | Details |
|---|---|
| Working Area (L x W) | 10000mm x 1800mm |
| Max. Positioning Speed (X/Y) | 120m/min |
| Accuracy (X/Y) | ±0.5mm/m |
| Repeatability (X/Y) | +0.03m |
Maintenance & care
Inspect the decoiler, feed mechanism and material path regularly. Keep the laser optics, nozzle and protective window clean. Check the assist-gas supply and cooling system where fitted. Inspect rollers, guides, belts, chains and drive components. Check sensors, electrical connections and cable routing. Remove scrap and dust from the cutting area and follow the manufacturer’s preventive maintenance schedule. Technical Parameter • Working Area (L × W): 10000 × 1800 mm • Max. Positioning Speed (X/Y): 120 m/min • Accuracy (X/Y): ±0.5 mm/m • Repeatability (X/Y): +0.03 mm
May we help?
- What are the main specifications of the HAN'S GRC4 1800?
- The HAN'S GRC4 1800 offers 10000mm x 1800mm working area (l x w), 120m/min max. positioning speed (x/y), ±0.5mm/m accuracy (x/y), +0.03m repeatability (x/y).
- What is the HAN'S GRC4 1800 used for?
- It is used for High-volume sheet-metal processing from coil, Automotive and auto-component sheet parts, Electrical enclosures and panel components, HVAC and general fabrication parts, Continuous-production sheet components.
- What maintenance does the HAN'S GRC4 1800 need?
- Inspect decoiler/feed mechanism and material path. Keep laser optics, nozzle and protective window clean. Check assist-gas supply and cooling/chiller condition where fitted. Inspect rollers, guides, belts/chains and drive components.
