D-T30
A high-speed mechanical CNC turret punch press built for precise, reliable and productive sheet metal punching.
- 300 kN Press capacity
- 240 hpm Hit rate
- 30 Tool stations
- ±0.1 mm Punching accuracy
Product description
The D-T30 is a mechanical CNC turret punch press designed for high-speed sheet metal production. With a 300 kN press capacity, a hit rate of up to 240 hpm and feeding speeds of up to 80 m/min, it delivers the productivity required for continuous punching operations. Its 30-station tooling configuration, maximum sheet size of 5000 × 1250 mm with one reposition and punching accuracy of ±0.1 mm make it suitable for demanding production environments where speed, repeatability and efficient material handling are essential.
Features
High-Speed Mechanical Punching
A maximum hit rate of 240 hpm supports fast punching cycles for continuous sheet metal production.
300 kN Press Capacity
The 300 kN punching capacity provides the force required for reliable processing across a wide range of sheet metal applications.
30-Station Turret
The 30-station tooling configuration provides flexibility for multiple punching operations without frequent tool changes.
Large Sheet Processing
A maximum sheet size of 5000 × 1250 mm with one reposition supports efficient processing of large-format sheets.
High-Speed Sheet Feeding
Feeding speeds of up to 80 m/min help reduce non-cutting time and maintain efficient production cycles.
3/4-Axis CNC Control
X, Y, T and C axis control enables accurate sheet positioning, turret movement and tool rotation during punching operations.
Precise Punching Performance
Punching accuracy of ±0.1 mm supports consistent hole placement and repeatable results across production batches.
Flexible Tooling Capability
A maximum tool diameter of Φ88.9 mm allows the machine to accommodate a broad range of punching requirements.
D-T30 specification
| Specification | Details |
|---|---|
| Brand | Dardontech |
| Product Series | T Series |
| Model | D-T30 |
| Product Type | CNC Turret Punch Press |
| Press Capacity | 300 kN |
| Hit Rate | 240 hpm |
| Max. Sheet Size | 5000 × 1250 mm with one reposition |
| Max. Diameter | Φ88.9 mm |
| Max. Sheet Thickness | 4 mm |
| Punching Accuracy | ±0.1 mm |
| Feeding Speed | ≤80 m/min |
| Tool Configuration | 30 stations |
| CNC Axes | 3/4 axes: X, Y, T, C |
| Main Motor Power | 5.5 kW |
| Air Pressure | 0.55 MPa |
| Dimensions | 4800 / 5200 / 2300 mm |
Maintenance & care
Regular inspection of the mechanical drive, tooling, turret and machine components helps maintain consistent punching performance. Tool condition and machine settings should be checked according to the manufacturer's recommended operating and maintenance procedures.
May we help?
- What is the punching capacity of the D-T30?
- The D-T30 has a press capacity of 300 kN and supports sheet thicknesses up to 4 mm.
- How fast can the D-T30 punch?
- The machine has a maximum hit rate of 240 hpm and a feeding speed of up to 80 m/min.
- How many tools can the D-T30 accommodate?
- The D-T30 comes with a 30-station tool configuration for flexible punching operations.
