Dardontech PBE-1000
A compact CNC bending machine with a 1000 mm bending length, ±135° bending range and up to 25 T pressing force for precision sheet forming.
- 1000 mm Bending length
- ±135° Bending angle
- 25 T Max pressing force
- 0.35 mm Min thickness
Product description
The Dardontech PBE-1000 is a compact CNC bending machine designed for precision sheet metal forming across a range of production requirements. It provides a maximum bending length of 1000 mm and supports sheet widths up to 1000 mm, with a bending angle of ±135°. Standard and heavy-duty configurations offer pressing forces of up to 14 T and 25 T respectively. The machine can process sheets from 0.35 mm, with maximum thickness capabilities varying by stainless steel, mild steel and aluminum. Angular precision of ±0.5 and straightness precision of ±0.2 support consistent bending results.
Features
1000 mm Bending Length
The 1000 mm bending length is suited to compact workpieces and sheet metal components requiring controlled forming.
±135° Bending Angle
The machine provides a broad bending range for forming components across different sheet metal applications.
Up to 25 T Pressing Force
The heavy-duty configuration provides up to 25 T of pressing force for higher-demand bending operations.
Flexible Material Capacity
The machine supports stainless steel up to 1.5 mm, mild steel up to 2.0 mm and aluminum up to 3.0 mm, depending on configuration.
0.35 mm Minimum Sheet Thickness
The machine can process sheet material from a minimum thickness of 0.35 mm for applications requiring fine sheet forming.
Precision Bending
Angular precision of ±0.5 and straightness precision of ±0.2 support repeatable forming results.
Standard and Heavy-Duty Configurations
Standard and heavy-duty versions provide different pressing-force and power configurations to suit varying production requirements.
Technical specification
| Specification | Details |
|---|---|
| Model | PBE-1000 |
| Max. Bending Height | 170 mm |
| Bending Angle | ±135° |
| Min. Sheet Thickness | 0.35 mm |
| Angular Precision | ±0.5 °/m |
| Straightness Precision | ±0.2 °/m |
| Working Voltage | 380V ±10% |
| Max. Bending Length | 1000 mm |
| Max. Sheet Width | 1000 mm |
| Min. Workpiece Size — Four Sides Bending | 170 mm |
| Min. Workpiece Size — Single Side Bending | 160 / 170 mm |
| Max. Pressing Force — Standard | 14 T |
| Max. Pressing Force — Heavy Duty | 25 T |
| Max. Sheet Thickness — SS | 1.0 / 1.5 mm |
| Max. Sheet Thickness — MS | 1.2 / 2.0 mm |
| Max. Sheet Thickness — AL | 2.0 / 3.0 mm |
| Power — Standard | 26 kW |
| Power — Heavy Duty | 28 kW |
Maintenance & care
Follow the manufacturer's recommended maintenance schedule for the selected PBE-1000 configuration. Regularly inspect the bending mechanism, tooling, electrical systems and CNC controls. Keep the working area clean and ensure routine lubrication, inspection and servicing are carried out according to the manufacturer's recommendations.
May we help?
- What is the maximum bending length of the Dardontech PBE-1000?
- The PBE-1000 provides a maximum bending length of 1000 mm and can accommodate sheet widths up to 1000 mm.
- What sheet thickness can the PBE-1000 process?
- The minimum sheet thickness is 0.35 mm. Maximum thickness varies by material and configuration, reaching up to 1.5 mm for stainless steel, 2.0 mm for mild steel and 3.0 mm for aluminum.
- What pressing force is available on the PBE-1000?
- The PBE-1000 is available with a standard pressing force of 14 T or a heavy-duty pressing force of up to 25 T.
